SKF 6204-2RSH/C3SKF Bearings

$18.25

SKF 6204-2RSH/C3 Bearing

Radial/Deep Groove Ball Bearing – Straight Bore, 20 mm ID, 47 mm OD, 14 mm Width, Double Sealed, Without Snap Ring

Status18 in stock
Categories

SKF 6204-2RSH/C3 Bearing

Radial/Deep Groove Ball Bearing – Straight Bore, 20 mm ID, 47 mm OD, 14 mm Width, Double Sealed, Without Snap Ring

Specifications

  • Bore Type
    Straight
  • Bore Diameter
  • Outside Diameter
  • Contact Angle
    Not Applicable
  • Overall Width
  • Closure Type
    Double Sealed
  • Snap Ring Included
    Without Snap Ring
  • Internal Clearance
    C3
  • Operating Temperature Range
    Max 250 °F
  • Cage Type
    Sheet metal
  • Precision Rating
    ABEC 3
  • Seal Type
    NBR Contact seal on both sides
  • Finish Coating
    Uncoated
  • Bearing Material
    Bearing steel
  • Cage Material
    Bearing steel
  • Inner Ring Width
    14 mm
  • Element Material
    Bearing steel
  • Fillet Radius
    1 mm
  • Max Rpm
    10000 rpm
  • Series
    62
  • Radial Dynamic Load Capacity
    3035 lbf
  • Radial Static Load Capacity
    1472 lbf
  • Manufacturer Catalog Number
    6204-2RSH/C3
  • Manufacturer Upc Number
    7316571819556
  • UPC_NO
    7316571819556
  • Weight
    0.25 lbs
  • Features & Benefits
    • Single Row Deep Groove Ball Bearing, steel cage, C3 fit, 2 seals
  • Description
    6204-2RSH/C3 SMALL DEEP GROOVE BALL BRG
  • Seal Material
    Nitrile Rubber
  • Product Type
    Radial & Deep Groove Ball Bearings
  • Long Description
    The 6204-2RSH/C3 is a 20 mm bore radial/deep groove ball bearing with 47 mm OD, 14 mm width, straight design, double sealed.

SKF Bearings

SKF bearings are a product line from SKF, a leading Swedish manufacturer of bearings and related products founded in 1907. SKF bearings are designed to reduce friction and support rotational or oscillating motion in diverse applications, including industrial equipment, renewable energy, and automotive systems. They offer various types of bearings, such as ball bearings, roller bearings, needle bearings, and spherical bearings, all manufactured to high-precision standards.
