102206 Bell & Gossett Series PR

102206 Bell & Gossett Series PR IB Iron Body Booster Pump Oil-Lubricated 1/6HP 1725RPM 115v 1Ph

Series PR cast iron pumps are dependable, in-line booster pumps intended to pump water through closed loop systems for heating and cooling. The Series PR is designed for applications that require increased flow and head pressures. The Series PR features a three-piece design, which includes a motor, bearing assembly and volute. This innovative design provides for easy field service as the bearings, shaft and seal are all housed within the bearing assembly. That assembly can then be easily repaired or entirely replaced without disturbing the other components of your pump. The Series PR’s resilient motor mounting is another feature unique to Bell & Gossett. The mounting, combined with spring-loaded couplers, means your pump will run quietly and efficiently. The Series PR features a plastic impeller. A tube of Bell & Gossett oil along with flange gaskets and mounting hardware are included with the pump. Flanges are available separately in 3/4″, 1″, 1-1/4″, and 1-1/2″.

BrandBell & Gossett
Tags,
Categories,
FacebookXPinterestRedditDeliciousLinkedinWhatsappEmail

102206 Bell & Gossett Series PR IB Iron Body Booster Pump Oil-Lubricated 1/6HP 1725RPM 115v 1Ph

Series PR cast iron pumps are dependable, in-line booster pumps intended to pump water through closed loop systems for heating and cooling. The Series PR is designed for applications that require increased flow and head pressures. The Series PR features a three-piece design, which includes a motor, bearing assembly and volute. This innovative design provides for easy field service as the bearings, shaft and seal are all housed within the bearing assembly. That assembly can then be easily repaired or entirely replaced without disturbing the other components of your pump. The Series PR’s resilient motor mounting is another feature unique to Bell & Gossett. The mounting, combined with spring-loaded couplers, means your pump will run quietly and efficiently. The Series PR features a plastic impeller. A tube of Bell & Gossett oil along with flange gaskets and mounting hardware are included with the pump. Flanges are available separately in 3/4″, 1″, 1-1/4″, and 1-1/2″.

Downloads

Zoning Reference Guide

Booster Pump Service Guide

B&G What To Know About Water System

SERIES 100, SERIES LR, NRF, NBF and SERIES PL BOOSTERS Warranty

NRF Submittals

NBF SSF Submittals

Wet Rotor Pump Specs

B&G Hydronic Products

PL Series Booster Pumps

Submittal-Series-PL

bg-series-ld3-hd3-pd_installation-and-service

bg-series-100-pr-hv-2-2half-ld3-hd3-pd_submittal (2)

Specifications

BrandBell & Gossett
MPN102206
Pump TypeCirculator
B&G SeriesSeries PR
B&G ModelPR IB
ModelPR-IB
Pump ConstructionIron Body-IB (Stl Imp)
Pump ClassBooster
Pump MountingIn-Line
Pump Connection Size3/4″, 1″, 1-1/4″, 1-1/2″
Pump ConnectionFlanged
Flanges IncludedNo
Motor HP1/6 HP
Motor RPM1725 RPM
Motor Voltage115V
Motor Phase1 Ph
Motor Hertz60 Hz
Motor EnclosureODP
Motor Frame SizePower Pack
Shaft Size1/2″
Impeller Size4-1/4″
Working Pressure125 psi
Max Temp225°F
Potable WaterNo
UPC683328022062
Weight30.30
