Bell & Gossett Series e-60 Bronze Pump

Bell & Gossett Series e-60 BE626S All Bronze Pump – 3/4HP, 1750RPM, 1PH, 115/230v

Bell & Gossett Series e-60 BE626S All Bronze Pump – 3/4HP, 1750RPM, 1PH, 115/230v

Bell & Gossett all bronze Series e-60 model BE626S in-line, three-piece centrifugal pump for potable water. This pump features a 3″ x 3″ x 5-1/4″ connection, 3/4 HP, single phase motor, unitized internal self-flushing mechanical seal, and 175 psi max working pressure. Series e-60 pumps offer a permanently lubricated XL-11 pump and motor bearing system and are dimensionally interchangeable with legacy Series 60 pumps.

BrandBell & Gossett
Categories,
FacebookXPinterestRedditDeliciousLinkedinWhatsappEmail

Bell & Gossett Series e-60 BE626S All Bronze Pump – 3/4HP, 1750RPM, 1PH, 115/230v

Bell & Gossett all bronze Series e-60 model BE626S in-line, three-piece centrifugal pump for potable water. This pump features a 3″ x 3″ x 5-1/4″ connection, 3/4 HP, single phase motor, unitized internal self-flushing mechanical seal, and 175 psi max working pressure. Series e-60 pumps offer a permanently lubricated XL-11 pump and motor bearing system and are dimensionally interchangeable with legacy Series 60 pumps.

Specifications

More Information
Brand Bell & Gossett
MPN 1EF145LF
Pump Type In-Line
B&G Series Series e-60
B&G Model Be626S
Model Be626S
Pump Size 3x3x5.25
Pump Construction All Bronze-AB
Pump Class Centrifugal
Pump Mounting In-Line
Pump Connection Size 3″
Pump Connection Flanged
Flanges Included Yes
Motor HP 3/4 HP
Motor RPM 1750 RPM
Motor Voltage 115/230V
Motor Phase 1 Ph
Motor Hertz 60 Hz
Motor Enclosure ODP
Shaft Size 1/2″
Impeller Size 4.375″
Working Pressure 175 psi
Max Temp 250°F
Potable Water Yes
Replaces B&G Model B626S
Weight 77.00

Downloads

B&G Series E-60 Pump Brochure

B&G Series E-60 Pump Instructions

B&G Series E-60 Pump Curves

B&G Series E-60 Pump Parts List

B&G Series E-60 Pump Specs



Drawings

B&G Series E-60 Pump Exploded View

Pump Quote

Please fill out this form in as much detail as possible and we can send you a quote on a pump. If you are replacing an existing pump, please upload the motor tag and pump tag. We stock many brands in our Surrey BC warehouse, find out if we have what you need in stock today! If we have it in stock you can get your pump usually within 3-5 days!

    Type Of Pump

    Pump Application

    Power Supply Required

    Bell & Gossett

    Bell & Gossett’s complete line of in-line and base-mounted centrifugal pumps and circulators can handle virtually any HVAC requirement. The pumps are engineered for exceptional performance and rugged durability. They are designed for easy maintenance and to be highly energy efficient. The pumps provide reliable operation in a variety of applications, including hydronic heating and cooling systems, industrial, refrigeration, cooling towers and irrigation.
