102214 Bell & Gossett 2″ NFI Cast Iron Booster Pump Oil-Lubricated 1/6HP 1725RPM 115v 1Ph

Series 2 NFI cast iron body pumps are dependable, in-line booster pumps intended to pump water through closed loop systems for heating and cooling. The Series 2 features a three-piece design, which includes a motor, bearing assembly and volute. This innovative design provides for easy field service as the bearings, shaft and seal are all housed within the bearing assembly. That assembly can then be easily repaired or entirely replaced without disturbing the other components of your pump. The Series 2’s resilient motor mounting is another feature unique to Bell & Gossett. The mounting, combined with spring-loaded couplers, means your pump will run quietly and efficiently. The Series 2 NFI features a plastic impeller. A tube of Bell & Gossett oil along with flange gaskets and mounting hardware are included with the pump.

BrandBell & Gossett
Tags, ,
Categories,
FacebookXPinterestRedditDeliciousLinkedinWhatsappEmail

102214 Bell & Gossett 2″ NFI Cast Iron Booster Pump Oil-Lubricated 1/6HP 1725RPM 115v 1Ph

Series 2 NFI cast iron body pumps are dependable, in-line booster pumps intended to pump water through closed loop systems for heating and cooling. The Series 2 features a three-piece design, which includes a motor, bearing assembly and volute. This innovative design provides for easy field service as the bearings, shaft and seal are all housed within the bearing assembly. That assembly can then be easily repaired or entirely replaced without disturbing the other components of your pump. The Series 2’s resilient motor mounting is another feature unique to Bell & Gossett. The mounting, combined with spring-loaded couplers, means your pump will run quietly and efficiently. The Series 2 NFI features a plastic impeller. A tube of Bell & Gossett oil along with flange gaskets and mounting hardware are included with the pump.

Downloads

Zoning Reference Guide

Booster Pump Service Guide

B&G What To Know About Water System

SERIES 100, SERIES LR, NRF, NBF and SERIES PL BOOSTERS Warranty

NRF Submittals

NBF SSF Submittals

Wet Rotor Pump Specs

B&G Hydronic Products

PL Series Booster Pumps

Submittal-Series-PL

bg-series-ld3-hd3-pd_installation-and-service

bg-series-100-pr-hv-2-2half-ld3-hd3-pd_submittal (2)

Specifications

Brand Bell & Gossett
MPN 102214
Pump Type Circulator
B&G Series Series 2″
B&G Model 2 NFI
Model 2-NFI
Pump Construction Cast Iron-NFI (Non-Ferrous Imp)
Pump Class Booster
Pump Mounting In-Line
Pump Connection Size 2″
Pump Connection Flanged
Flanges Included No
Motor HP 1/6 HP
Motor RPM 1725 RPM
Motor Voltage 115V
Motor Phase 1 Ph
Motor Hertz 60 Hz
Motor Enclosure ODP
Motor Frame Size Power Pack
Shaft Size 1/2″
Impeller Size 3-3/8″
Working Pressure 125 psi
Max Temp 225°F
Potable Water No
UPC 683328022147
Weight 36.91
