Armstrong Pump E11.2 – 1″ – 1-1/2″ Flgd, Cast Iron, 1/6 HP, 1 PH Circulator Pump Also Available In Bronze For Potable Water

The Armstrong Pump E11.2B is a 1/6 HP, single phase dry motor cast iron circulator pump that features a stainless steel shaft, permanently lubricated bearings, and a bellows-style mechanical seal with silicon carbide wear surface. Armstrong E.2 Series pumps can perform up to 140 gpm and 60 feet of head. The E.2 Series offers long-term performance, lasting components, and a refined product design for extended durability and low lifetime cost. It features an easy access to mechanical seal and a compact design that minimizes flange-to-flange dimensions. The E.2 Series is ideal for heating or cooling systems, such as hot water, geothermal, radiant panel, and snow melt in large residential and light commercial installations.

BrandArmstrong
Categories,
FacebookXPinterestRedditDeliciousLinkedinWhatsappEmail

Armstrong Pump E11.2 – 1″ – 1-1/2″ Flgd, Cast Iron, 1/6 HP, 1 PH Circulator Pump Also Available In Bronze For Potable Water

The Armstrong Pump E11.2B is a 1/6 HP, single phase dry motor cast iron circulator pump that features a stainless steel shaft, permanently lubricated bearings, and a bellows-style mechanical seal with silicon carbide wear surface. Armstrong E.2 Series pumps can perform up to 140 gpm and 60 feet of head. The E.2 Series offers long-term performance, lasting components, and a refined product design for extended durability and low lifetime cost. It features an easy access to mechanical seal and a compact design that minimizes flange-to-flange dimensions. The E.2 Series is ideal for heating or cooling systems, such as hot water, geothermal, radiant panel, and snow melt in large residential and light commercial installations.

Specifications

Manufacturer (Brand) Armstrong Fluid Technology
Armstrong Pump Series (Armstrong Fluid Technology) Series E.2
Model E11.2
MPN (Manufacturer Part Number) 182202-651
UPC (GTIN) N/A
Connection Type Flanged
Connection Size 1″, 1-1/2″, 1-1/4″
Flanges Included No
Pump Type Booster
Construction Cast Iron
Application Heating & Cooling
Mounting Type In-Line
Motor HP 1/6 HP
Motor Phase Single
Hertz 60Hz
Motor RPM 3300 RPM
Voltage 120v
Motor Enclosure ODP
Max Temp 230°F
Working Pressure 150 psi
Weight 15.1000

Downloads

Armstrong Circulator Replacement Parts Brochure

Armstrong Circulator Replacement Parts

Armstrong Astro 2 Brochure

Armstrong Cross Reference Chart

Armstrong Circulator Install Instructions

Armstrong Impellers

Armstrong

The Armstrong circulator pump is one of the best on the market and with their expertise in fluid flow, heat transfer, variable speed, and demand based control, Armstrong Fluid Technology leads the fluid systems industry, including plumbing and hvac in providing the most energy efficient and cost effective solutions to building professionals and owners around the globe. We carry both the commercial and residential line of Armstrong Pumps including commercial series 4030 base mounted end suction pumps, series 5200 & 5240 sump sewage pumps and series 4300 vertical in-line pumps, series 4360 vertical in-line pumps, 4380 vertical in-line pumps. Most residential pumps are normally stocked including the Armstrong Astro circulators, Armstrong series E.2 circulators and the Armstrong series S&H 3-piece circulating pumps.
